IO-1020 ELD Micro Device
- Built-in J1939 Type II 9-pin connector supporting both new and legacy vehicles
- WiFi 801.11b/g/n up to 150Mbps and simultaneous AP and Station modes
- Bluetooth 4.2 Class 1 supporting BR/EDR and LE dual-mode
- Multi-constellation GNSS receiver with built-in high-gain antenna
IO-2041 Advanced OBD-II Logger
- Built-in SAE J1962 Type B 16-pin connector supporting 12V and 24V vehicles
- USB micro-B port for configuration loading, firmware update, and file download
- Real-time clock with supercapacitor backup (6 month backup time)
- 3-axis accelerometer
- 3-axis gyroscope
- LTE Category M1, NB-IoT, and GPRS/2G cellular modem with built-in high-gain antennas
- nanoSIM slot, push-push style, user accessible
- GPS receiver with built-in high-gain antenna
IO-2050 OBD-II Tracker
- Built-in SAE J1962 Type B 16-pin connector supporting 12V and 24V vehicles
- 3-axis accelerometer
- 3-axis gyroscope
- WiFi 801.11b/g/n up to 150Mbps and simultaneous AP and Station modes
- Bluetooth 4.2 Class 1 supporting BR/EDR and LE dual-mode
- LTE Category M1, NB-IoT, and GPRS/2G cellular modem with built-in high-gain antennas
- nanoSIM slot or eSIM built-in
- Multi-constellation GNSS receiver with built-in high-gain antenna
IO-2055 OBD-II Tracker (Remote)
- Identical feature set to the IO-2050 OBD-II Tracker, remotely installed for security or privacy
- Can be conncted to either a J1962 OBD-II connector or a J1939 Type II 9-pin connector when using the optional cableset.
- Support for both new and legacy vehicles
IO-2151 (USB)
- Design based on the IO-2050 OBD-II Tracker to provide advanced vehicle data to other fleet peripherals
- Built-in J1962 OBD-II 16-pin connector supporting both new and legacy vehicles
- Can be connected to other vehicle configurations (ie J1939 Type II 9-pin, 6 pin, etc) using an optional accessory adapter
- USB connection for interface to other peripherals (dash cameras, tablets, etc)
- Wireless Bluetooth and wifi connectivity
- 3-axis accelerometer
IO-2152 (RS-232)
- Design based on the IO-2050 OBD-II Tracker to provide advanced vehicle data to other fleet peripherals
- Built-in J1962 OBD-II 16-pin connector supporting both new and legacy vehicles
- Can be connected to other vehicle configurations (ie J1939 Type II 9-pin, 6 pin, etc) using an optional accessory adapter
- RS-232 serial connection for interface to other peripherals (dash cameras, tablets, etc)
- Wireless Bluetooth and wifi connectivity
- 3-axis accelerometer
IO-5041 Advanced J1939 Logger
- Built-in J1939 Type II 9-pin connector supporting both new and legacy vehicles
- USB mini-B port for configuration loading, firmware update, and file download
- Real-time clock with supercapacitor backup (6 month backup time)
- 3-axis accelerometer
- GPS receiver with built-in high-gain antenna
